| Product Image | Description | Cat. No. |
|---|---|---|
 |
CAPP Rondo Disc Tube Rotator | CRR-0800D |
 |
50 mL disc plate with tube holder | CRR-0800D-D50 |
 |
15 mL disc plate with tube holder | CRR-0800D-D15 |
 |
2 mL / 5 mL disc plate with tube holder | CRR-0800D-D05 |
|
50 mL tube holder | CRR-0800D-TH50 |
|
15 mL tube holder | CRR-0800D-TH15 |
|
5 mL tube holder | CRR-0800D-TH05 |
|
Front Nut | CRR-0800D-FN |
|
Power Adaptor | CRR-0800D-PA |
The CAPPRondo Disc Tube Rotator is microprocessor controlled, offering intelligent performance that includes a convenient last run memory feature for added ease of use. It provides adjustable speed settings, ranging from 10 to 80 RPM, with precise control and an accuracy of +/- 1 RPM to ensure consistent results. The pulse mode enables alternating clockwise and anticlockwise rotation with 2-second pauses, facilitating thorough and uniform mixing of samples.
A digital display is included for convenient and easy-toread monitoring of all operational parameters, enhancing usability. The rotator features a variable timer that can be set from 1 to 99 minutes, along with an infinite mode for continuous operation when needed. Users have the capability to programme and save up to nine custom-defined programs, allowing for efficient and repeatable workflows. The rotator’s angle can be adjusted from 0° to 90°, offering flexibility to accommodate a wide range of experimental needs and preferences.The auto power-on feature ensures that the device automatically resumes and completes its run after a power failure, minimizing disruption to your work. The CAPPRondo Disc Tube Rotator supports a variety of attachments, including configurations for 12 tubes of 50 mL, 24 tubes of 15 mL, or 44 tubes of 2 mL, making it highly versatile for different laboratory applications.
| Specification | Value |
|---|---|
| Capacity (supplied with chosen disc plate) | 12 tubes x 50 mL, 24 tubes x 15 mL, 44 tubes x 2 mL |
| Programmable Mode | Yes, up to 9 user-defined programs |
| Variable Speed | 10-80 RPM |
| Run Time | 1-99 mins & infinite |
| Motor Type | BLDC motor |
| Pulse Mode | Yes, alternating clockwise and anticlockwise motion with 2 sec stops |
| Angle of Disc Plate | Adjustable from 0-90 degrees |
| Weight (Capacity) | Up to 2 kg |
| Digital Display | Yes |
| Input Voltage | 24V |
| Dimensions (W x D x H) | 383 x 325 x 325 mm |
| Protection Class | IP 21 |
